Automatic Aluminum Foil Lunch Box Production Line 3 Cavity 4 Cavity

Anhui Aoxuan Heavy Industry Machine Co., Ltd.
Contact Now

Automatic Aluminum Foil Lunch Box Production Line 3 Cavity 4 Cavity

  • 1
  • 2

Brand Name : Aoxuanzg

Model Number : JF21-63

Certification : CE,ISO

Place of Origin : China

MOQ : 1 set

Price : $17800-38000

Payment Terms : L/C, Western Union, MoneyGram, T/T

Supply Ability : 500 sets per year

Delivery Time : 50-60 days

Packaging Details : Standard export packing

Warranty : 2 Years

Condition : New

Mold : 3-Cavity 4-Cavity

Pressure of Machine : 63T

Feed speed : 20-50M/min

Feeding length : 30-999mm

Contact Now

3-Cavity 4-Cavity Automatic Aluminum Foil Lunch Box Production Line Price



1. Feeder with lubricating oil system:

maximum. Roll diameter: ¢800mm
maximum. Roll width: 700mm
Feed speed: 20-50M/min
Feeding length: 30-999mm
Feed tolerance: +/-0.3mm



2. 45T high precision pneumatic press:
Body working plate hole size: 300*300mm
Travel time: 60-100 times/min
Stroke height: 240mm
Working plate thickness: 100mm
maximum. Mould installation height: 390mm
Bottom size of slider, handle hole size: 220*400mm
The distance from the center of the slice to the body: 340mm
Mould height adjustment: 80mm
Die handle hole size: 60mm
Table size: 1000*800 mm



3. Two-track stacker
Conveyor belt width: 550mm
Current collector belt height: 1100-1300mm
Minimum container size: 120 x 100mm (size can be adjusted)
Maximum container size: 360 x 250 (size can be adjusted)
Maximum working speed: 65 pc/min



4. Waste collector
Speed: 1450rpm
Capacity: 4kw
Lift: 1.5m



5. Mould: Mould price depends on your container size.
Customers need to send us the aluminum foil container first, then we will calculate the mold cost according to your size



Main Configuration:

Serial No. Part Description Brand Place of Origin
1. The Whole Structure AOXUANZG Maanshan,Anhui,China
2. Slide AOXUANZG Maanshan,Anhui,China
3. Crankshaft AOXUANZG Maanshan,Anhui,China
4. Connecting Rod AOXUANZG Maanshan,Anhui,China
5. Gears AOXUANZG Maanshan,Anhui,China
6. Hydraulic Overload Protection Kingair Taiwan
7. Double Valve TACO Japan
8. Cam Controller Estun Nanjing,Jiangsu,China
9. Dry Friction Clutch OMPI Italy
10. Sealing Element SOG Taiwan
11. AC Contactor Schneider France
12. Intermediate Relay Omron Japan
13. Breaker Schneider France
14. Power Door Lock Schneider France
15. Transformer Chint Zhejiang,China
16. Grease Pump IHI Japan
17. Bearings NSK or HRB,ZWZ,LYC Japan or China
18. Pneumatic Components AirTAC Taiwan
19. Photo-electronic Device Lion Zhejiang,China
20. Motor TECO Taiwan
21. Frequency Transformer Delta Taiwan
22. Anti Vibration Press Mount HengRun Zhejiang,China
23. Lamp HengTe

Shandong,China



Automatic Aluminum Foil Lunch Box Production Line 3 Cavity 4 CavityAutomatic Aluminum Foil Lunch Box Production Line 3 Cavity 4 Cavity



Our Service:

Pre-sales.
* Project design, performance introduction, technical agreement, contract signing, packaging
* Inquiry and consulting support.
* Sample testing support.

In-sales.
* We will provide you with the latest progress in the product assembly, packaging and transportation.

After-sale.
* We will provide free accessories for the damage to non - human parts.
* Training how to install the machine, training how to use the machine with video and so on
* And our technical staff can go abroad to provide technical guidance.
